replacement Volt Battery Indicator Meter Gauge for EZGO Club Car Yamaha Golf Cart 72V VDC
Specs – Battery Type: Lead Acid. Voltage Types: 12V, 24V, 36V, 48V, 72V. Display Type: 10-bar LED indicate. Terminals: Max 3, 3/16″ spades. Mounting Type: U-Shape Bracket. Operating Temperature: -40?? C to +85?? C. Storage Temperature: -50??C to +90?? C. Operating Humidity: 95% RH (Non-condensing) at 38??C; Refer to images 2 & 3 for more information
Includes – (1) Battery Indicator & (3) Terminal Connectors; comes as shown in the first image
When the 2nd (from left) LED flashes, this indicates “energy reserve.” When both the 1st & 2nd LED flash, this indicates “empty” and new battery is needed to replace old one. Range indication: Green: 41%-100%, Yellow: 21%-40%, Red: 20% or less. When in use with a new battery, it should be powered on for at least 2 minutes to indicate the real battery state.
