Golf Cart Voltage Converter Regulator DC 36V 48V to DC 12V 30A 350W, input voltage range is DC 30-60V, 6-pin plug
Universal fit for Club Car, EZGO, Yamaha and other golf carts
Connects entire battery pack instead of just one battery which improves the life of the battery pack
5 Safty Protections: Over-load, Over-current, Over-temperature, Short-circuit, Over-voltage; stable and reliable performance
The Industry grade DC converter is widely used in golf cart, forklifts, bus, large trucks, motor, solar generate electricity, display screen of bus and taxi, car audio device, LED, intercom and monitor system, etc.
Universal Golf Cart Voltage Reducer Converter DC 36V 48V to 12V 30A 350W for EZGO Club Car Yamaha
Intelligent Protection
High Efficiency:95%
Qualified integrated circuit ensures higher conversion rates.
5 Safty Protections
Over-load, Over-current, Over-temperature, Short-circuit, Over-voltage
Specifications:
Input Voltage: 30-55V DC
Output Voltage:12V DC
Output Current :10A
Output Rated Power: 350W
Line Regulation: 0.2%
Load Regulation :0.2%
Voltage Accuracy :1.5%
Operating Temperature:-30~70C
Aluminum Strip Shell
Provide good heat dissipation and solidity to prolong service life. Blue coating prevents rusting and gives a good look.
Glue Seal
For waterproof, dustproof, shockproof, to cope with a variety of harsh environment.
Built-in Fuse
Ensures circuit safety. Wire harness is for easy storage and prevents pulling.
Extra Connector
The converter can be easily disconnected when not in use.
Moderate Size
6.93*4.72*1.97 inch
You can secure it to any flat surface by installing screws in the holes.
Five Wiring
Yellow – 30-55V battery input (+)
Black – 30-55V battery input (-)
Green – key switch “ON” position (or battery input +)
Red – 12V output(+)
Blue – 12v memory wire of clock, radio, etc (or not connected)
Widely used
In golf cart, forklifts, bus, large trucks, motor, solar generate electricity, display screen of bus and taxi, car audio device, LED, intercom and monitor system, etc.
