Universal Golf Cart Turn Signal Kit with Horn Brake Light Switch, 9-Pin Plug Upgrade Wiring Harness – 12V

Upgrade kit make your golf cart has turn signal, horn, hazard flashing, brake lights functions, fits all golf carts with 9-pin plug light wiring harness
Kit includes: turn signal lever with headlight/horn switch & 9-Pin wiring harness, hazard flashing switch, controller box, steering column cover, brake pad, horn, clamps and screw set, wiring diagram instruction
12 Volt operation(voltage reducer is required on 36v/48v), the black button on horns backside is for volume control could adjust it when power connected
The kit is connected to the light unit via a 9-pin plug.
100% Satisfaction guarantee, 1 year refund or replacement
Universal Golf Cart Turn Signal Kit with Horn Brake Light Switch, 9-Pin Plug Upgrade Wiring Harness – 12V
Make your cart street legal, and will have turn signal, horn, hazard flashing, brake lights etc.
9-Pin plug Inerface:
Puple: Horn+
White: Rear left turn lamp
Yellow: Foot step-
Brown: Rear right turn lamp
Blue: Headlight and rear light
Black: Power V-
Red: Power V+
Green: Front Right turn lamp
Gray: Front left turn lamp
