LED BARS DISPLAY —- There are 3 colors(1 red, 2 yellows and 7 greens) for 10 LED bars with 10% capacity per each; It will be only lighten the related LED bar for remain battery capacity measurement, but display the change of charge/discharge status by always on,shut-down or flashes.
BATTERY LEVEL METER —- What should be noticed that this device is only suitable for lead acid battery powered equipment but not Trojian’s; It help you to know the charge time by how much battery power left (related voltage discharge percentage).
HOW TO INSTALL —- You can drill an accurate panel cut-out size 37x25mm(1.5x 1inches) on proper place of equipment for installation; 2 power connection diagrams to be chosen: direct & key switch.
KEY POINT—- User must connect the “C” pin with positive(+) pin to keep the indicator getting an normal real-time battery power left.
OTHER —-Favorable waterproof rate(Surface waterproof IP65);Well-compeleted accessories;Excellent after-sales and technical support(2 years warranty)
For more than 10 years, Runleader has focused on product development and manufacturing in the fields of hour meter, battery indicator, multi-function meter, days timer,service for the garden machinery industry, outdoor power vehicle equipment, transportation vehicles, such as: generators, pumps,chainsaws,outboards,lawn mowers,compressors and others,provide well-known European and American customers with quality products and services.
Runleader RL-BI003 12V/24V,36V,48V Battery Status Meter,Lead Acid Battery Applicably, Battery Power Charge &Discharge Display.
2.Charging Reminder When battery power is low, it will flash to remind by red and yellow bars alternatively.It will display the charging status by voltage percentage change from 90% to 10%(empty to full).
1.Battery Level Indicator
Measure and display the current capacity for lead acid battery
Determine how much power left for battery.3 colors(1 red, 2 yellows and 7 greens) for 10 LED bars with 10% capacity per each.It indicate the full battery capacity by first green LED bar, and low battery capacity by final red LED bar.Different battery capacity will be displayed by related voltage percentage discharge from 10% to 90% (full to empty).
3.Runleader has established a complete laboratory for testing and improving the product’s quality
High Pressure Water Washer Testing
Display with PC transparent board can keep it away from the damp or moist.It also prevent the strong shock when it is cleaning.
Drop testing
Favorable anti-vibration performance can suffer strong vibrations when the equipments is working.
High & Low temperature
It can works well in temperature environments temperature: -40 ??C – +70 ??C.
Installation method
Once LED bar scan from F to E, that means connection is successful.Widely used for Motorcycle, Golf cart,Forklift,Electric car and stacking machine etc.
SPECIFICATIONS
Product
RL-BI003
System Voltage
12/24V,36V,48V
Applicable Battery
Lead-acid Battery (Depending on model)
Capacity (Regular model)
1 Red 2 Yellow 7 Green color LED for indicator
Capacity (SR model)
10 Red LED for indicator
Operating Voltage
+/- 25% of nominal voltage
Operating Current
??100mA nominal
Operation Temperature
-10?? to +50??
Storage Temperature
-40?? to +70??
Product Size
53x32x24mm??2.08*1.25*0.94inches??
Waterproof rate
IP65
Accessories list
Cable tie*2; Battery CR2450*1;User manual*3;Box*1
