100% Brand new and high quality. Easy to use and install,which is durable for a long time to use.
prongs in 9 pin plug,3 prongs on the top,middle 3 pin holes are empty,3 prongs on the bottom.
Suitable for many different types and styles of motorcycles.
Featuring one normally closed and two normally open contacts in a TPST (Triple pole, single throw) orientation. So, three inputs and three outputs.”
We Would Provide the Quality Assurance and the Money Back Guarantee to ensure that you can buy it without any concern. We are committed to create the best product service for each customer. If this product does not meet your expectations, please feel free to contact us, we will try the best to deal with till you satisfied.
Product Description
Description:
1.100% Brand new and high quality.
2.Easy to use and install,durable
3.6 prongs in 9 pin plug,3 prongs on the top,middle 3 pin holes are empty,3 prongs on the botton
4.Suitable for many different types and styles of motorcycles.
5.Featuring one normally closed and two normally open contacts in a TPST
(Triple pole, single throw) orientation. So, three inputs and three outputs. In more detail…
When the switch is in the OFF position:
Input 1 & Output 1 are connected
Input 2 & Output 2 are disconnected
Input 3 & Output 3 are disconnected
In the ON position:
Input 1 & Output 1 are disconnected
Input 2 & Output 2 are connected
Input 3 & Output 3 are disconnected
In the PARK position:
Input 1 & Output 1 are disconnected
Input 2 & Output 2 are connected
Input 3 & Output 3 are connected
Specification:
Wire Length: 230mm
Number of Keys: 2
Switch Positions: 3(Off-On-Park)
Required Fixing Hole Diameter: 22.5mm
Max Barrel Diameter: 38mm (approx)
Connector Type: 9 way 2.8mm Motorcycle Connector
Note: Please allow 0.5-1 inch difference due to manual measurement.(1 inch=2.54cm)
Package included:
1 x Ignition Key Switch
2 x Keys
