??Spec??48 Volts 4 Terminals Heavy Duty Solenoid with Silver Contacts 48V 586-120111 Series
??Application??Compatible with Club Car Electric 1995-1998 and Power Drive and Yamaha Electric 48 volt G19 Golf Cart
??Application??Compatible with E-Z-GO Shuttle 2 to 6 passenger series 950 series Titan and XI-875 electric 1995 and newer
??Replace for?? Club Car 101883601 1018836-01 EZGO 73231G01 73231-G01 Yamaha JR1-H1950-00 Motrec 486222 White Rodgers 586-120111
??1 Year Warranty??Take care not to overtighten the nut/terminal during installation.
??Spec??
Voltage: 48V
Terminal: 4
Resistance: 214 Ohm
Work Current: 450A
Inrush Current: 540A
Housing: PMC
High Current Stud: Around 5/16 Inch
Low Current Stud: 0.19 Inch
Body Shell Plating: Zinc Coating
Contact Material:Isolated Coil Silver Alloy Contacts
??Application??
Replace for Club Car 101883601 1018836-01
Replace for E-Z-GO 73231G01 73231-G01
Replace for Yamaha JR1-H1950-00
Replace for White Rodgers 586-120111
Compatible with Club Car Electric 1995-1998 and Power Drive
Compatible with E-Z-GO Shuttle 2 to 6 passenger series 950 series Titan and XI-875 electric 1995 and newer
Compatible with Yamaha Electric 48 volt G19 Golf Cart 1996 to 2001 and 2002 to 2014 Yamaha 48 volt electric models G22, G23 and G27 and G29 YDRA Drive
Compatible with Motrec and Karrior
??1 YEAR WARRANTY??Please feel free to contact us for any questions, we will give quick response asap.
Recommended to be used as a replacement solenoid when upgrading to a higher amp controller and can be used as a replacement in many other applications where high current capability is required.
