Input 28-60V, output 12V, rated power 120W, safely converts 24V/36V/48V/60V electric golf cart battery to 12 Volts 10 Amps
Application to 12V golf cart LED light kit(headlight, underglow light, roof light), electric horn, screen, monitoring system and DIY etc.
Size 100*42*26.5mm, aluminium shell with epoxy potting, waterproof IP67, dust-proof, anti-shock
Yellow Wire Input(+) from battery, Green Wire switch input(+) from keyswitch, Black Wire ground(-) battery, Red Wire 12V switch output(+)
Golf cart voltage reducer for ezgo yamaha club car electric, safely converts 24V/36V/48V/60V electric golf cart battery to 12 Volts 10 Amps
Size: 100*42*26.5mm
Input: 28-60V
Output: 12V
Rated power: 120W
Conversion erfficiency: >=91%
Waterproof IP67
Built in fuse, over voltage protection, over-current protection(Max 12A)
Yellow Wire – Input(+) from Battery
Green Wire – Switch Input(+) from Keyswith
Black Wire – Ground(-) Battery
Red Wire – 12V Switch Output(+)
