Assembled with smart chip, features Over-current /Over-load /Low-load /Short-circuit /Over-heat intelligent protection
Compact aluminium shell with epoxy potting, 100% waterproof, anti-dust, anti-shock protection and better heat dissipation
These voltage converters are excellent power transformers, can work safely and reliable in -40C~80C range. And all converters are offered 1 year replacement assurance
Specifications
Input Voltage: 48V nominal; Input Range:30V~60V
Input Current: 10A (max) ; No-load input current: 10mA
Output Voltage: DC 12V 2% ; Output Current: 30A
Ripple Wave: 50Mv
Starting Delay time: 2S
Efficiency:96%
Operating Temperature:-40 ~ 80
Weight: 500g / 17.6oz
Package Including
1x DC Voltage Reducer 48V to 12V 30A 360W
Excellent product design and processing technology
IP68 Waterproof
The strict glue pouring process is waterproof, moisture-proof, seismic, and adapts to various harsh environments.
Aluminum shells improve better heat dissipation effect and sturdiness to extend service life.
SMT Process
FR-4 multilayer lines, resistors, capacitors, and switch MOS tubes are SMD components with high integration, reliability, and stability.
Compact Size
The compact aluminum shell with epoxy potting is anti-shock, damp-proof,anti-dust protection, and has better heat dissipation
Synchronous Rectification Technology
The synchronous rectifier circuit uses MOSFET instead of a rectifier diode to greatly reduce the loss of the rectifier and improve the converter efficiency
Intelligent Protection
Assembled with smart chip–has features of Over-current /Over-load /Low-load /Short-circuit /Over-heat intelligent protection
Wide Applications
These compact size dc voltage reducer converters are high reliability power transformers. They can work safely and reliability within temperature range -40C~80C.
Widely used for golf cart, motor, speaker, GPS, LED car display screen, air-conditioner, electric fan, solar energy, photo-voltaic power, DVD, industrial equipment etc.
