RATED RANGE:Max operating voltage for the Fuse Block is 32V DC, this fuse box with max 30A per circuit & 100A per panel.The fuse box can operate stably at a current of 120A for a short time.This will protect your branch circuit components from excessive current damage.
Warning Indicator:There’s a red LED light next to each fuse,Red LED Warning light will light up immediately when the corresponding fuse is blown.Automotive fuse block will indicate exactly where there is a short circuit or any other fault,Remind you to check and replace the blown fuse.
Superior Material:Made of environment friendly PBT material, this 12 volt 6 Way fuse block meets all the standards of an ideal fuse box. It has high strength, insulation, heat resistance and flame resistance. Damp proof cover included,After installation, it can prevent water from eroding the circuit.
Easy to install: Fuse Panel provides 6 fuses and 6 ground positions and is very easy to install. Make messy lines look clean and tidy.Comes with multifunctional DIY sticker for convenient examination & repair. Make it easy to repair the electrical circuits of your vehicles or boats!
Widely Use:This 6-Circuit Blade Fuse Box widely used in Motorcycle Cars, Buses, Tankers, Boat, Truck, SUV, Yacht, RV, Ships etc.
6 Way Fuse Block, 12 Volt Waterproof Boat Fuse Panel
fuse box can operate stably at a current of 120A for a short time.This will protect your branch circuit components from excessive current damage.
This 6-Circuit Blade Fuse Box widely used in Motorcycle:Cars, Buses, Tankers, Boat, Truck, SUV, Yacht, RV, Ships etc.
Input Voltage
12V-24V DC
Max operating voltage
32V DC
Max Amperage per block
100A
Max current of each circuit
30A
Positive connection
M5 5MM bolt
Cathode connection
M4 4MM bolt
Quantity of circuits
6
Mounting Torque Rating
8 in-lb(0.9Nm) max
Torque Rating
20in-lb(2.25Nm) max
Input Wire Size
#4-6 AWG
Output Wire Size
#12-16 AWG
Working temperature
-40 ~ 150
Package includes:20A Fuse x 4, 15A Fuse x 4, 10A Fuse x 2, 5A Fuse x 2, Sticker x 2, Screws x 4.
