Material: ABS Waterproof: IP65
High reliability, low cost and compact size. Suitable for lead-Acid battery.
Works with 48V Lead-Acid Batteries in Golf Carts, Forklifts, Trucks, RV’s, ATV’s, UTV’s, Scooters, Boats and More
Capacity: 1 Red 2 Yellow 7 Green color LED for indicato
Operation:
Only when the battery is properly charged then the 10th LED (far right) will be lighted. As batterys state of charge decreases, successive LED lights up, only one at a time. When 2nd (from left) LED flashes, indicating “energy reserve”. When both 1st and 2nd LED flash, indicating “empty”, new battery is needed to replace old one. Battery indicator memorized the battery state is full when leaving factory. When use with a new battery, it should be powered on for at least 2 minutes to indicate the real battery state
Cococart 48V LED Battery Indicator Meter Gauge
For EZGO Club Golf Cart Yamaha Car Marine Jet Ski
Suitable battery: Lead-Acid battery
Operating Voltage: 48V
Operating Current: 20 mA
nominal Accuracy: +/- 0.5 percent
Operating and Storage Temperature: -20 to 85-
Specifications:
Material: ABS
Waterproof: IP65
Net Weight: 21g / 0.8oz
Product Size: 2.1 * 1.3 * 1.2inch
Capacity
1 Red 2 Yellow 7 Green color LED for indicator
Green: 41~100%Yellow: 21~40%Red: 20% less
Good quality
High reliability Low cost Compact size.
Universal Use Works with 48V Lead-Acid Batteries in Golf Carts, Forklifts, Trucks, RV’s, ATV’s, UTV’s, Scooters, Boats and More
Package List1 * Battery Indicator 1 * Pack of Accessories 1 * User Manual
