This torque converter fits 8 – 18 hp engines
Engagement range: 1600 – 3300 RPM
No Instructions Included
.aplus-tech-spec-hide-loading {
visibility: visible !important;
}
Jeremywell 40 Series Torque Converter Kit Clutch Pulley 1″ Driver 5/8″ Driven
The Series 40 torque converter kit for go-karts and mini bikes consists of a 5/8″ bore driven pulley, and a 1″ bore driver clutch pulleyThis torque converter kit is a replacement for the Comet torque converter
40 Series Torque Converter Kit
Replaces Comet 40D Series Torq-A-Verter Models:
209133A, 209133, 209139A, 209139, 209151A, 209151, and Manco 2432
Driven Clutch 5/8″ Bore: A symmetrical in line small engine clutch, can be used on engines with 8-18HP.
Driver Clutch 1″ Bore: Engagement range: 1600 – 3300 RPM
Belt: Series 40 uses 7/8″ wide belts which comes included.
40 Series Torque Converter Driven Clutch 5/8″ Bore
Replaces Comet 40D Series Torq-A-Verter Models:
209133A, 209133, 209139A, 209139, 209151A, 209151, and Manco 2432
Driven Clutch 5/8″ Bore: A symmetrical in line small engine clutch, can be used on engines with 8-18HP.
Driver Clutch 1″ Bore: Engagement range: 1600 – 3300 RPM
Belt: Series 40 uses 7/8″ wide belts which comes included.
Jeremywell 40 Series Torque Converter Driver Clutch 1″ Bore
Replaces Comet 40D Series Torq-A-Verter Models:
209133A, 209133, 209139A, 209139, 209151A, 209151, and Manco 2432
Driven Clutch 5/8″ Bore: A symmetrical in line small engine clutch, can be used on engines with 8-18HP.
Driver Clutch 1″ Bore: Engagement range: 1600 – 3300 RPM
Belt: Series 40 uses 7/8″ wide belts which comes included.
Belt
Replaces Comet 40D Series Torq-A-Verter Models:
209133A, 209133, 209139A, 209139, 209151A, 209151, and Manco 2432
Driven Clutch 5/8″ Bore: A symmetrical in line small engine clutch, can be used on engines with 8-18HP.
Driver Clutch 1″ Bore: Engagement range: 1600 – 3300 RPM
Belt: Series 40 uses 7/8″ wide belts which comes included.
40 Series Torque Converter Kit
Driven Clutch 5/8″ Bore
Driver Clutch 1″ Bore
Belt
Torque Converter Kit Specifications
Driven Clutch
5/8″Driver Clutch
1″Belt
7/8″Fits
8-18 HP EnginesEngagement Range
1600-3300 RPMKeyway Size
3/16 Inch Cast-in-Key
Jeremywell 40 Series Torque Converter Kit Clutch Pulley 1″ Driver 3/4″ Driven
Jeremywell 40 Series Torque Converter Kit Clutch Pulley 1″ Driver 5/8″ Driven
Jeremywell 40 Series Torque Converter Kit Clutch Pulley 1″ Driver 7/8″ Driven
Driver Clutch
1″
1″
1″
Driven Clutch
3/4″
5/8″
7/8″
