36V Starter Solenoid Relay Switch 20468G1 114-3611-020 586-117111 Fit for Club Car DS Columbia E-Z-GO Yamaha Electric
36V Starter Solenoid Relay Switch 20468G1 114-3611-020 586-117111 Fit for Club Car DS Columbia E-Z-GO Yamaha Electric
36V Starter Solenoid Relay Switch 20468G1 114-3611-020 586-117111 Fit for Club Car DS Columbia E-Z-GO Yamaha Electric
REPLACE FOR?? E-Z-GO 20468G1 Trombetta 114-3611-020 White Rodgers: 586-117111 586-117111-3 586-906S1 586-906 Club Car 1016072 Columbia 71458-87 Yamaha JF3-H1950-00 PRESTOLITE 15-552 SBJ4301 JOHNSON ELECTRIC 5122340 SO51223 Miscellaneous Vendor 586-117111-5 6C026 MELEX 510204 TAYLOR-DUNN 72-501-38
??Compatible With?? models Club Car DS, electric, 1988-2005, Columbia Electric 1987 and newer, E-Z-GO electric, 1989 and newer, Yamaha Electric G4, G8, G9, G11 and G16
??SPEC?? 36 Volt 4 Terminal Continuous Duty
??NOTE?? Take care not to overtighten the nut/terminal during installation
??1 YEAR WARRANTY?? Please feel free to contact us for any questions, we will give quick response asap
??Spec??
Voltage: 36V
Terminals: 4
Duty??Continuous
High Current Stud: Around 5/16 Inch
Low Current Stud??Around 0.19 Inch
Mounting Type: Flat 180
Contacts Material: Red Copper
Housing Material: PMP
Body Shell Plating: Zinc Plating
Potted coil: Copper
Resistance: 42
Work Curre
