Used on 1982-current E-Z-GO Electric Vehicles and 1982-1993 2-Cycle Gas Vehicles.
This hub/drum is a replacement for the earlier (before 1982) hub & drum andhas the star spline instead of the straight key.
Has a 3/4-Inch center hole with a 24-tooth star spline.
The drum is held in place by a castellated nut (5/8-Inch x 18tpi) and a thick (.118-Inch) flat washer.
Package included 2 pieces. Easy Installation & 1 year Warranty.
Basic Information of Brake Drum/Hub Assembly
Fit on Golf Cart
E-Z-GO Electric Vehicles and 2-Cycle Gas Vehicles.
Year
1982-Up( E-Z-GO Electric Vehicles )and 1982-1993 (2-Cycle Gas Vehicles).
Replaces OEM Part
19186-G1
Package Contains
Included 2 pieces Brake Drum/Hubs Assembly
Fit on Golf Cart
Used on 1982-current E-Z-GO Electric Vehicles and 1982-1993 2-Cycle Gas Vehicles.
Drum/Hub Assembly
Has a 3/4-Inch center hole with a 24-tooth star spline.The drum is held in place by a castellated nut (5/8-Inch x 18tpi) and a thick (.118-Inch) flat washer.
Package Contains
Included 2 pieces Brake Drum/Hubs Assembly
